  1. 4.2 mm Pitch 90 Degree Right Angle Wafer Connector
    1. Packing:Tube, PE bag
    2. Delivery time:7-15 days
    3. UL:Yes
    4. ROHS Compliant

inquire now

product details

  1. 2D(PDF) Drawing
  2. Approval Specification

4.2mm Pitch Dual Rows 180 Degree DIP Wafer Connector

Specification:

Current Rating: 9.0AMP

Withstand Voltage: 1000V AC/DC

Contact Resistance: 20MΩ Max

Insulation Resistance: 1000MΩ Min

Operation Temperature: -25ºC to +85ºC

Insulation Material: PA66(UL94V-2)

Contact Material: phosphor bronze or brass

Contact Plating: Au or Sn over Ni
